MK01-KIT Bluetooth evaluation board

MK01-KIT Bluetooth evaluation board is a universal development tool that highlights the capabilities of the MK01 series Bluetooth Module. MK01-KIT BLE evaluation board provides you with a quick and easy way to develop MK01 series BLE module or even Nordic® nRF52832 solution.

• Applicable for MK01 series nRF52832 Bluetooth Module
• Provides a complete I/O pin of MK01 series Bluetooth Module
• Power supply options: 5V USB Type-C, External 3.3V, CR2032 coin cell battery
• USB to UART
• NFC-A Tag

Previous
Next

MK01-KIT Bluetooth evaluation board

MK01-KIT Bluetooth evaluation board is a universal development tool that highlights the capabilities of the MK01 series Bluetooth Module. This board provides you with a quick and easy way to develop MK01 series module or even Nordic® nRF52832 solution.


• Applicable for MK01 series nRF52832 Bluetooth Module
• Provides a complete I/O pin of MK01 series Bluetooth Module
• Power supply options: 5V USB Type-C, External 3.3V, CR2032
coin cell battery
• USB to UART
• NFC-A Tag



Evaluation Board

MK01-KIT Bluetooth evaluation board is applicable for MK01A and MK01B mini Bluetooth® module. It is a full-featured BLE evaluation board that provides a complete I/O pin and debug pin(SWD) out to headers, external 32.768 kHz crystal setup, DC/DC regulator setup, power port over USB Type-C, NFC antenna FPC connector, one RESET button, one user button and one user RGB-LED. The Bluetooth evaluation boards also provide the option to be powered from a CR2032 coin cell battery and have a current sense hole to allow for convenient current measurements.
